62ft Boom Hoist Genie Z-62/40
The Genie Z-62/40 boom hoist offers exceptional 62-foot working height, impressive horizontal reach, and smooth articulating performance. Designed for demanding construction and maintenance tasks, it provides safe, stable access in tight or elevated areas, delivering reliable productivity and precise control for a wide range of industrial applications.
SKU: Z62
| Specification | Details |
|---|---|
| Max Working Height | 68 ft 7 in (20.87 m) |
| Max Platform Height | 61 ft 11 in (18.87 m) |
| Horizontal Reach | 40 ft 9 in (12.42 m) |
| Up & Over Clearance | 25 ft 7 in (7.8 m) |
| Platform Capacity | 227 kg |
| Platform Size | 36 in × 96 in (0.91 m × 2.44 m) |
| Stowed Height | 8 ft 4 in (2.54 m) |
| Stowed Length | 26 ft 9 in (8.15 m) |
| Stowed Width | 8 ft 2 in (2.49 m) |
| Wheelbase | 8 ft (2.44 m) |
| Ground Clearance | 16 in (0.41 m) |
| Drive Speed | 4 mph (6.4 km/h) |
| Gradeability | 45% |
| Turntable Rotation | 355° non-continuous |
| Jib Range | 5 ft jib with 135° motion |
| Power Source | Diesel engine |
| Machine Weight | Approx. 10,433 kg |
